2. Plug-in MicroUSB to GlowCube™ XL/Titan/IPS then plug another end of USB to your computer.
If everything goes well, GlowCube™ XL/Titan/IPS will display title screen with GlowCube logo.
3. Download and run GlowCube software as Administrator ** For client version 1.38 and beyond, you can just double click at our exe file to run.
The file is portable, extract from .zip to any folder. Then double click on green icon executable file (GlowCube_XL_X.XX.exe) Note : Some antivirus may has false positive, we can guarantee that our software is safe. You may need to add exception on them. For the first 3-10 seconds is synchronization process, the PC try checking firmware capability so the data you see may not accurate. After few seconds the data will be shown accurately.
FW 1.70+v1.38K for GlowCube XL/Titan/IPS (Recommended for 2021 and earlier model)
FW 1.85+FPSv1.39C Recommended for GlowCube LCD Series with the firmware graphic framerate display support (FW v1.85+, see firmware version at top right of title screen), Installation and running of Riva Statistic Server in the background is needed (included in the zip file) -- see section 5 for more details
New config uploader for firmware 1.83 (existing user with 1.82 please use previous version)
Support world clock page and timezone can be set (input +11 to -11 in timezone.txt)
Support new algorithm for refreshing and updating the screen.
Up to 25% faster synchronization process and update rate.
A bunch of bugs Fixed.
UAC elevation to Administrator (no more right clicking and Run as administrator)
You may have your Windows runs our GlowCube at startup by following these instuctions.
Test if your GlowCube screen shows everything correctly.
Press WindowsKey + R
Type Shell:startup then press Enter, Startup folder will show up.
Create Shortcut of the .exe files and drag to the Startup folder (or dragging while holding ALT key). After shortcut is created, right click, choose Properties > Shortcut tab > Advance > tick on "Run as Administrator"
If your Windows fail to start the program at boot, please do the following steps.
Press Windows Key type user account you will see ( Change user account control setting), move the bar to bottom "never notify"
Run Registry Editor by pressing Windows Key type regedit and browse to HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows\CurrentVersion\Policies\System you will see "Enable LUA" Change from 1 to 0
Reboot your computer afterward, everything should be all set.
4. Wait for few seconds, the information will be shown on screen. (first synchronization may takes up to 10 seconds)
The program icon will stay hidden in Windows traybar. Please leave it run during using your screen. You can change the options and display modes by right clicking on the icon.
โหมดการแสดงผลมีดังนี้
Brief Shows important info like %Load, CPU/GPU temperature.
CPU Monitor Shows detailed CPU info and per-core stat.
GPU Monitor Shows GPU temp and load graph.
CPU Load Gauge Shows CPU load percent in analog gauge style.
GPU Load Gauge Shows GPU load percent in analog gauge style.
CPU Temp GaugeShows CPU temperature in analog gauge style.
CPU Temp Gauge Shows GPU temperature in analog gauge style.
Chart and Bar displays graph style and Progress Bar
Rig monitor (FW v1.5+) Shows multiple GPUs info.
Nerd Stat text mode with a lot of info.
Device Table show all devices info in one screen.
Disk Monitor monitor utilization and temp up to 2 disks.
5. (Optional) How to show framerate (FPS) with RTSS
For devices with firmware 1.85 and beyond. There will be FPS display with the help of program Riva Statistic Server which automatically detect when to detect and show FPS. We bundled RTSS_Setup.exe file, doubleclick to install.
Run Riva Statistic Server the small icon will show at the Windows' traybar on the bottom right corner, right click and choose Show
For configuring (first time only) please configure at the following, you may start Application detection level to Low for conserving your computer resource, if it cannot detect your game, increase to medium.
The monitor will display framerate while you are playing the game. Otherwise, it displays as ----
6. (Optional) WiFi Setting
edit wificonfig.ini using your Windows notepad.
ssid is the name of Access Point (SSID) you are using. Case-sensitive. Leave blank if you don't want your device to connect to Wi-Fi.
password Access Point password If no AP password, leave value blank.
clock_waittime The waiting time between title screen to clock screen (configurable 6-30 seconds)
slideshow_rotation The SD Card slideshow duration for each image. (configurable 6-30 seconds)
timezone Timezone for your simple clock (eg. 7 for Thailand, -5 for New York)
random_image Config how the SD Card image slideshow will be played. (0=Sequencial, 1=Random)
After you finished editing, save this file and close all GlowCube clients. Execute Config_Uploader.exe, the terminal will popup, wait for it done (may takes from few seconds to 1-2 mins). Hit Enter key to close the console as instructed.
SD Card insertion: The front of SD Card (printed side) face to the back of the screen.
For optimal slideshow display. Adjusting width and height of the image matches with screen resolution (480x320) will have the best display. From hardware limitation, putting too large image files may make the screen hang or overheat. Need to reset screen and adjust image file size in this case.
For MicroUSB Model
For Type-C Model
